The Crusoe Studio

£23,450 including VAT



The Crusoe Studio is a 5 metre by 3 metre handcrafted cedar clad timber framed building and can be designed and built to your requirements.



Fully insulated and internally boarded and plastered, the garden room makes for an ideal extension to your home.  Cool in the summer and warm in the winter it can be used all year round whether it be a home office, music or art studio, kids playroom or gym.



Constructed from 100mm x 50mm section planed timber, clad on the outside with top quality Western Red Cedar board and erected, insulated, boarded, plastered and painted on site.



The floor and roof sections are fully insulated and clad with 18mm exterior ply.  The roof is then covered with a one piece rubber roof covering (EPDM) and black UPVC profiled fascia board fitted.



The Crusoe Studio incorporates a set of anthracite grey or black aluminium three leaf bi-folding doors with two aluminium framed windows as in our picture - all are fitted with Pilkington K double glazed sealed units.



Decking is fitted at the front and side of the Crusoe Studio for a wraparound effect.

Our rooms can be clad either vertically or horizontally.



The perfect garden room, home office, studio or games room to complement your house and garden.  A family run business based in Nottingham, we can supply, deliver and erect throughout the UK.

Specification

The price (£23,450 including VAT) includes delivery, installation and all the specifications listed below;



  • 5 metres wide by 3 metres deep.

  • Timber floor: Consists of 18mm OSB ply board on 75 x 50mm pressure treated floor joists and incorporating 75mm rigid insulation to be seated on concrete pads/slabs or solid concrete slab if required (you can either get a local builder to quote for and build the base or we can do it for you, to be quoted for at the time of site visit) Internal floor: 18mm exterior ply.

  • Overall dimensions: 5 metres wide x 3 metres deep with a external canopy overhang and one metre deep side wall.

  • External height at front elevation: 2.5m.

  • Internal height at front elevation: 2.15m.

  • Wall construction: 100mm x 50mm section timber with breathable membrane and clad with 98mm x 18mm Cedar tongue and groove board which can be fitted vertically or horizontally. The walls are then insulated with 100mm rock wool insulation or similar and plaster boarded and plaster skimmed.

  • Roof: One piece EPDM single membrane rubber roof covering (50 year life span) with black UPVC fascia board, gutter trim and guttering. Fitted on to 18mm exterior OSB plyboard on 150mm x 50mm roof timbers incorporating 150mm of insulation, plasterboarded and internally skimmed.

  • Doors: Aluminium three leaf bi-fold anthracite grey or black doors 3m wide x 2.0m high. Pilkington K toughened glass with multiple locking system.

  • Windows:  Aluminium anthracite grey or black framed windows with Pilkington K toughened glass sealed units.  One fixed glazed panel 190cm high x 50cm and one openable top hung window 120cm wide x 50cm high.

  • Internal finish:  Ceilings and walls painted in white emulsion throughout. Skirting board and architrave fitted.

  • A choice of laminate flooring throughout.

  • Decking: Fitted at the front and one side of the Crusoe Studio one metre deep.

  • Electrics: Includes 4 chrome double sockets, 8 chrome sunken downlights, 4 external downlights and dedicated consumer unit.

  • Standard electrical connection to your existing supply by our fully qualified and registered electrician included.

  • We now include a hard wired smoke alarm with battery backup and a 1000 KW wall mounted heater as standard at no extra cost.
